Point D’ACCES TP-LINK SANS FIL BI-BANDE AC1750 PoE GIGABIT(EAP245)

POINT D’ACCES TP-LINK SANS FIL BI-BANDE AC1750

CARACTERISTIQUES MATERIELLES

Interface Gigabit Ethernet (RJ-45) Port *2 (Support IEEE802.3af PoE and Passive PoE )

Bouton Reset

Alimentation 802.3af/A PoE

48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Consommation 12.3 W

Dimensions (LxPxH) 205.5 × 181.5 × 37.1 mm

Type d’antenne Internal Omni

2.4GHz: 3* 4dBi

5GHz: 3*4dBi

Montage Ceiling /Wall Mounting (Kits included)

Système de verrou physique Yes

Hardware Watch Dog Yes

CARACTÉRISTIQUES WIFI

Standards WiFi IEEE 802.11ac/n/g/b/a

Fréquence 2.4GHz and 5GHz

Vitesse du signal 5GHz:Up to 1300Mbps

2.4GHz:Up to 450Mbps

Fonctions WiFi Multiple SSIDs (Up to 16 SSIDs, 8 for each band)

Enable/Disable Wireless Radio

Automatic Channel Assignment

Transmit Power Control (Adjust Transmit Power on dBm)

QoS(WMM)

MU-MIMO

Seamless Roaming

Band Steering

Load Balance

Airtime Fairness

Beamforming

Rate Limit

Reboot Schedule

Wireless Schedule

Wireless Statistics based on SSID/AP/Client

Sécurité WiFi Captive Portal Authentication

Access Control

Wireless Mac Address Filtering

Wireless Isolation Between Clients

SSID to VLAN Mapping

Rogue AP Detection

802.1X Support

64/128/152-bit WEP / WPA / WPA2-Enterprise,

WPA-PSK / WPA2-PSK

Puissance de transmission CE：

≤19dBm(2.4GHz)

≤23dBm(5GHz)

FCC:

≤25dBm(2.4GHz)

≤27dBm(5GHz)

ADMINISTRATION

Administration Centralisée Omada Software Controller

OC200

APP support Yes

Cloud Access Yes (Through Omada Software Controller or OC200)

Alertes Email Yes

DEL ON/OFF Yes

Administration de contrôle d’accès des adresses MAC Yes

SNMP Yes

Journal système local/distant Local/Remote Syslog

Telnet Yes

Administration par interface WEB HTTP/HTTPS

L3 Management Yes

Multi-site Management Yes

Management VLAN Yes

AUTRES

Certification CE, FCC, RoHS

Contenu de l’emballage AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP245

Gigabit Passive PoE Adapter

Power Cord

Mounting Kits

Installation Guide

Système requis Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux

Environnement Operating Temperature: 0℃~40℃

Storage Temperature: -40℃~70℃

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
