Interface Fast Ethernet (RJ-45) Port *1(Support IEEE802.3af PoE)
Bouton Reset
Alimentation PoE or external 9VDC/0.6A power supply
Consommation 2.8W
Dimensions 189.4×172.3×29.5mm
Type d’antenne Internal 2* 4dBi Omni
Montage Ceiling /Wall Mounting (Kits included)
CARACTÉRISTIQUES WIFI
Standards WiFi IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Fréquence 2.4-2.4835GHz
Débit du signal 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Sensibilité de réception 300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER
Fonctions WiFi Multiple SSIDs (Up to 8 SSIDs)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Sécurité WiFi Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK
Puissance de transmission CE:
<20dBm
FCC:
<26dBm
ADMINISTRATION
Accès Cloud Omada Yes
Omada App Yes
Contrôleur Cloud Omada Yes
Administration Centralisée • Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Contrôleur Logiciel Omada Yes
Accès Cloud Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Contrôleur Logiciel EAP
Alertes Email Yes
DEL ON/OFF Yes
Administration de contrôle d’accès des adresses MAC Yes
SNMP v1,v2c
Journal système local/distant Local/Remote Syslog
Telnet Yes
SSH Yes
Administration par interface WEB HTTP/HTTPS
Administration VLAN Yes
AUTRES
Certification CE, FCC, RoHS
Contenu de l’emballage 300Mbps Wireless N Ceiling Mount Access Point EAP115
Power Adapter
Mounting Kits,
Installation Guide
Système requis Microsoft Windows 10/8/7/Vista/XP
Environnement Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
